Page #3 background image
# = Fast-moving Parts 3 02/02
* = Non-Illustrated Parts
FRS23W3A Publication No.
5995366761
FREEZER DOOR
A = FRS23W3A (FRS23W3AQ3)
B = FRS23W3A (FRS23W3AQ4)
C = FRS23W3A (FRS23W3AQ5)
D = FRS23W3A (FRS23W3AW3)
E = FRS23W3A (FRS23W3AW4)
F = FRS23W3A (FRS23W3AW5)
POS. NO PART NO DESCRIPTION
1 240390604 A B C D E F Gasket-door,white
4A 240367301 A B C D E F Bin-door,frzr-upper
4B 240359001 A B C D E F Bin-door
11 240451822 A B C - - - Door-frzr,bisque ,complete assy
11 240451818 - - - D E F Door-frzr,white ,complete assy
13A 240456904 A B C - - - Door Stop,bisque ,frzr
13A 240456902 - - - D E F Door Stop,white ,frzr
18 218762706 A B C - - - Handle-door,bisque
18 218762701 - - - D E F Handle-door,white
21A 5308016566 A B C D E F Screw,hex washer hd,8-15A x 0.625, low profile
21C 218781100 A B C D E F Screw,pan head ,8-18 x 0.625
22A 240328202 A B C D E F Bearing-hinge,closer
22C 240328402 A B C D E F Bearing-hinge,upper
37A 215870633 A B C - - - Trim-handle, 2.47", bisque, w/satin AL band
37A 215870629 - - - D E F Trim-handle, 2.47", white, w/satin AL band
68 240465801 A B C D E F Chute-ice
96 240345505 A B C D E F Plug,door foam hole ,white
* 240323201 A B C D E F Wiring Harness
* 240352101 A B C D E F Connector-water,straight
* 5303918256 A B C D E F Dispenser heater kit
