Frigidaire FRS23W3A User Manual

# = Fast-moving Parts 9 02/02
* = Non-Illustrated Parts
FRS23W3A Publication No.
5995366761
A = FRS23W3A (FRS23W3AQ3)
B = FRS23W3A (FRS23W3AQ4)
C = FRS23W3A (FRS23W3AQ5)
D = FRS23W3A (FRS23W3AW3)
E = FRS23W3A (FRS23W3AW4)
F = FRS23W3A (FRS23W3AW5)
POS. NO PART NO DESCRIPTION
2 240434601 A B - D E - Trim-basket
2 240434603 - - C - - F Trim-basket
11 240338801 A B C D E F Shelf-freezer,flip-up
11A 240338701 A B C D E F Shelf-freezer,fixed wire
11B 240338703 A B C D E F Shelf-freezer,fixed wire
24 240373107 A B C D E F Frame-refr shelf,cantilever
25 240354501 A - - D - - Cover-crisper pan,upper
25 240354502 - B C - E F Cover-crisper pan,upper
25A 240354601 A - - D - - Cover-crisper pan,lower
25A 240354602 - B C - E F Cover-crisper pan,lower
26 240354706 A B C D E F Pan-crisper,upper
27 240354806 A B C D E F Pan-crisper,lower
29 240357705 A B C D E F Trim-shelf,front
39 240430705 A B C D E F Trim-shelf,front
39B 240430701 A B C D E F Trim-shelf,front
40 240350622 A B C D E F Glass-shelf,refr shelf ,(3)
41 240357805 A B C D E F Trim-shelf,rear
47 240350631 A B C D E F Insert-pan cover,glass
47A 240350614 A B C D E F Insert-pan cover,glass
49 240338401 A B - D E - Basket-sliding
49 240530401 - - C - - F Basket-sliding
51 240343002 A B C D E F Hanger-basket,RH
52 240343102 A B C D E F Hanger-basket,LH
54 240351901 A B C D E F Plug-hanger,right hand
55 240352001 A B C D E F Plug-hanger,left hand
81 5308016566 A B C D E F Screw,hex washer hd, 8-15A x 0.625, low profile
97 240453001 A B C D E F Water Tank Assy,coiled tubing, no filter
100 240326301 A B C D E F Cover-water tank
101 218493100 A B C D E F Screw,hex washer head ,8-18AB x 1-3/4
126 218867401 A B C D E F Channel,auger mtg ,LH
126 218867402 A B C D E F Channel,auger mtg ,RH
* 215328300 A B C D E F Clip,cantlvr shelf
SHELVES
