# = Fast-moving Parts 9 02/01
* = Non-Illustrated Parts
FRT18B4A Publication No.
5995349601
A = FRT18B4A (FRT18B4AQ0)
B = FRT18B4A (FRT18B4AW0)
POS. NO PART NO DESCRIPTION
1 # 240406401 A B Condenser,static
1* 240409301 A B Spacer-cond tube,black
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10 ,grounding
4 # 218944001 A B Drier-filter,R134a System
6 # 240375301 A B Wiring Harness, machine compt, w/ service cord
6* # 240385401 A B Wiring Harness,freezer section
6* # 240388701 A B Wiring Harness,control box
14 # 5303918208 A B Defrost Heater Kit
15 # 5303918205 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240313502 A B Trough-drain
18 240362301 A B Insulation Block,RH
20 240362401 A B Insulation Block,LH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330001 A B Plate-compr mtg
22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B Grommet-compr mtg,(4)
25 240420301 A B Screw-shoulder
26 240332601 A B Pan-defrost drain
27 3161461 A B Nut-lock,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 # 5303918233 A B Compressor,R134a ,w/ electricals
30 # 218721113 A B Starter-PTC
32 218740800 A B Clamp,elec cont mtg ,compressor
41 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
44 5303001199 A B Clamp-wiring harness, strain relief, galv steel
55 # 218909901 A B Capacitor-run,220 VAC ,15 microfarad
57 240403601 A B Clip-wiring harness
82 5304418225 A B Roller-rear,comp base ,(2)
83 215164200 A B Pin-roller,(2)
84 240359601 A B Tube-drain,lower
85 240346201 A B Tube-connector,suction
* # 5303918207 A B Heat Exchanger Kit,suction line
* # 5303918234 A B Hot Tube Repair Kit,Service
SYSTEM
