# = Fast-moving Parts 11 05/99
* = Non-Illustrated Parts
FRT18IPRH Publication No.
5995322897
ICE MAKER
C = FRT18IPRH (FRT18IPRHD0)
D = FRT18IPRH (FRT18IPRHW0)
POS. NO PART NO DESCRIPTION
1 5303015131 - - C D Tube-water inlet,71" ,valve-to-IM
2 3206348 - - C D Spring,shut-off arm
3 3206299 - - C D Plate-I.D.
4 3206301 - - C D Gear
5 3206303 - - C D Plate-mounting
6 3206305 - - C D Screw-ground wire,8-32 x 1/4
7 # 3206306 - - C D Motor-ice maker
8 3206312 - - C D Spacer-holding sw
9 3206313 - - C D Cam
10 3206315 - - C D Clamp
11 # 3206319 - - C D Thermal Cutoff,icemaker ,complete assy
12 # 3206349 - - C D Harness-wiring,IM internal ,with plug
12 3206321 - - C D • Connector Plug,wiring harness
13 # 3206322 - - C D Thermostat Assy,ice maker
14 3206323 - - C D Screw-switch mtg,4-24 x 3/4 ,sw to support,(2)
15 # 3206324 - - C D Switch,(3)
16 3206326 - - C D Support
17 # 5303320545 - - C D Mold-ice maker,radius cube ,with heater
18 3206328 - - C D Ejector
19 3206330 - - C D Bearing & Inlet
20 3206331 - - C D Screw,8-18 x 0.375 ,(2)
21 3206332 - - C D Ice Stripper
22 3206333 - - C D Arm,shut-off
23 3206334 - - C D Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 - - C D Lever-arm
25 3206336 - - C D Screw-arm levr/sprt,8-18 x 9/16
26 3206337 - - C D Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 - - C D Screw-sw&spcr/plate,4-40 x 1
28 3206339 - - C D Screw-timing stop,4-40 x 3/8
29 3206340 - - C D Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 - - C D Screw-timing,8-32 x 1
31 3206342 - - C D Insulator
32 3206343 - - C D Plate-valve switch
33 3206344 - - C D Spring
34 3206345 - - C D Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 - - C D Screw-gear/cam,6-20 x 0.437
36 3206347 - - C D Cover-ice maker,complete
37 5303320544 - - C D Data Sheet,ice maker
38 5303207445 - - C D Envelope-data sheet
39 # 3206358 - - C D Harness-wiring,ice maker
40 5305877995 - - C D Sealing Strip
41 5308000039 - - C D Screw,hex wshr hd ,8-32CA x 0.500 ,srratd head
43 5303001199 - - C D Clamp-wiring harness,strain relief ,galv steel
44 5308000133 - - C D Clamp,nylon ,.75 OD tube
45 218843800 - - C D Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
46 5303001193 - - C D Clamp-inlet tube,metal
47 5308000205 - - C D Adapter-water sply,straight
48 5308000200 - - C D Nut,7/16 x 20 ,nylon
49 5303001147 - - C D Plug-harness hole,(2)
52 215456100 - - C D Tube-water inlet
55 # 218720300 - - C D Valve-water,120 V 60 Hz ,flow restricter
55* 5303015102 - - C D Cap-water valve
59 5303001191 - - C D Sleeve-tube insert
60 218362500 - - C D Screw,hex washer head ,8-18AB x 1.250
61 218721500 - - C D Bracket-leveling,ice maker
62 215230500 - - C D Screw-bracket mtg,pan head ,8-32T x 0.375
64 5303001549 - - C D Clamp-copper tube,steel
