# = Fast-moving Parts 5 05/99
* = Non-Illustrated Parts
FRT18PRH & FRT18IPRH Publication No.
5995322897
CABINET
A = FRT18PRH (FRT18PRHD0)
B = FRT18PRH (FRT18PRHW0)
C = FRT18IPRH (FRT18IPRHD0)
D = FRT18IPRH (FRT18IPRHW0)
POS. NO PART NO DESCRIPTION
1 218672501 A B C D Cover-fan
2 5303307351 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 218722200 A B C D Damper-fan cover,black
5 # 218649000 A B C D Fan Blade,black
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303205118 A B C D Bracket-motor mtg,front
10 3206451 A B C D Cover-evap coil
10* 5303209814 A B C D Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B C D Plug-hole,factory test
12 215079000 A B - - Plug-harness hole,round
12 215079100 A B - - Plug-wtr inlet tube,round
13 # 218878701 A B C D Motor-evap fan
14 5303322992 A B C D Bracket-motor mtg,rear
17 218725700 A B C D Trough-drain
18 215245000 A B C D Support-evap cover,(2)
19 5303001198 A B C D Tube,rubber
22 215774911 A - C - Plug-button,almond ,upr hinge holes
22 215774901 - B - D Plug-button,white ,upr hinge holes
23 5303269702 A B C D Tube-drain,w/seal ring
24 5303207353 A B C D • Seal Ring,drain tube
25 215774100 A B C D Spout-drain tube,w/mounting pins
29 5308000007 A B C D Washer,.34 x .62 x .05 ,nylon
29 5308011326 A B C D Washer,.34 x .62 x .02 ,nylon
30 5304409595 A B C D Bracket-lower hinge
30* 215882300 A B C D Tapping Plate,lower hinge ,(2)
35 218220102 A - C - Bracket-ctr hinge,almond
35 218220101 - B - D Bracket-ctr hinge,light grey
36 218251300 A B C D Pin-center hinge
37 5303321082 A - C - Trim-cabinet corner,almond
37 5303321081 - B - D Trim-cabinet corner,white
38 3206100 A B C D Bracket-upper hinge
40 3206105 A - C - Cover-upper hinge,almond
40 3206101 - B - D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf/rod mtg ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,LH
42 215880100 A B C D Screw-hinge mtg,hx wshr hd ,1/4-20 x 0.685,(2)
43 218724000 A B C D Roller Assy,front ,complete
43* 218703002 A B C D • Roller
43* 5308009790 A B C D • Spring-roller adj
43* 5308000186 A B C D • Washer,.34 x .62 x .10 ,nylon
43* 5308009761 A B C D • Bolt-roller adj
43* 3051070 A B C D Screw 10-24 X 7/16,hx wshr hd ,10-24 x 7/16
44 5303283014 A B C D Roller Assy,metal housing
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
47 218233300 A B C D Channel-shelf mtg,side ,(2)
48 5303292395 A B C D Channel-shelf mtg,center
49 218362500 A B C D Screw,hex washer head ,8-18AB x 1.250
56 218220300 A B C D Pin-lower hinge
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625 ,hng/mlln,thrd form
72 218915402 A - C - Grille/Kickplate,almond ,w/fasteners
72 218915401 - B - D Grille/Kickplate,white ,w/fasteners
73 218896804 A B C D • Fastener-grille,button ,(2)
78 5308000039 A B C D Screw,hex wshr hd ,8-32CA x 0.500 ,srrated hd
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C D Bracket-connector
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875 ,(6)
98 215099711 A - C - Plug-button,almond ,ctr hinge hole
98 215099701 - B - D Plug-button,white
* 5308016571 A B - - Plug-button,cabinet liner ,icemaker holes
* 5303305325 A - C - Paint,touch-up ,almond
* 5303305324 - B - D Paint,touch-up ,white
