# = Fast-moving Parts 9 05/99
* = Non-Illustrated Parts
FRT18PRH & FRT18IPRH Publication No.
5995322897
SYSTEM
A = FRT18PRH (FRT18PRHD0)
B = FRT18PRH (FRT18PRHW0)
C = FRT18IPRH (FRT18IPRHD0)
D = FRT18IPRH (FRT18IPRHW0)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B C D Condenser
1* 5303208866 A B C D Spacer-cond tube,black
2 5308000296 A B C D Bracket,condenser mtg ,(4)
2* 5308009617 A B C D Washer,ext tooth lock ,#10 ,grounding
4 # 218541000 A B C D Drier-filter,R134a System
5 # 218878500 A B C D Harness-wiring,control/divider
6 # 215257004 A B C D Harness-wiring,compressor
7 # 5316254901 A B C D Cord-electric power
8 5303001197 A B C D Cover-wiring
13 # 218429306 A B C D Heat Exchanger,suction line
14 # 3206453 A B C D Heater-defrost
15 # 3206452 A B C D Evaporator
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 5303207493 A B C D Insulator-evap,plastic
18 5308013648 A B C D Insulation Block,RH
19 5303007287 A B C D Insulation Plug,RH
20 5308017227 A B C D Insulation Block,LH
21 # 5316269001 A B C D Thermostat-defrost
22 218802500 A B C D Plate-compr mtg,with rail
23 218254500 A B C D Grommet-compr mtg,(4)
24 5308003633 A B C D Washer-compr mtg
25 5308003596 A B C D Clip-compressor mtg
26 215372500 A B C D Pan-defrost drain
27 5303001348 A B C D Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D Pan Retainer Kit,Service
29 # 218846902 A B C D Compressor,R134a ,w/o electricals
30 # 218721103 A B C D Starter/Overload Assy
32 218740800 A B C D Wire-bale
41 5308000039 A B C D Screw,hex wshr hd ,8-32CA x 0.500 ,srratd head
43 5303001199 A B C D Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B C D Clamp,nylon ,.75 OD tube
45 218843800 A B C D Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
45 5300141713 A B C D Screw,hex wshr hd ,8-32 x .625 ,spec
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
55 # 216236200 A B C D Capacitor-run,180-200 VAC ,15 microfarad
* # 3916557 A B C D Hot Tube Repair Kit,Service
