# = Fast-moving Parts 11 02/99
* = Non-Illustrated Parts
FRT18TRC Publication No.
5995317921
ICE MAKER
A = FRT18TRC (FRT18TRCW7)
B = FRT18TRC (FRT18TRCD7)
POS. NO PART NO DESCRIPTION
1 5303015131 A B Tube-water inlet,71" ,valve-to-IM
1* 3206276 A B Tube-valve to IM,plastic
2 3206348 A B Spring,shut-off arm
3 3206299 A B Plate-I.D.
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire,8-32 x 1/4
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-holding sw
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff,icemaker ,complete assy
12 3206321 A B Connector Plug,wiring harness
12 # 3206349 A B Harness-wiring,IM internal ,with plug
13 # 3206322 A B Thermostat Assy,ice maker
14 3206323 A B Screw-switch mtg,4-24 x 3/4 ,sw to support,(2)
15 # 3206324 A B Switch,(3)
16 3206326 A B Support
17 # 5303320545 A B Mold-ice maker,radius cube ,with heater
18 3206328 A B Ejector
19 3206330 A B Bearing & Inlet
20 3206331 A B Screw,8-18 x 3/8 ,(2)
21 3206332 A B Ice Stripper
22 3206333 A B Arm,shut-off
23 3206334 A B Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 A B Lever-arm
25 3206336 A B Screw-arm levr/sprt,8-18 x 9/16
26 3206337 A B Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 A B Screw-sw&spcr/plate,4-40 x 1
28 3206339 A B Screw-timing stop,4-40 x 3/8
29 3206340 A B Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 A B Screw-timing,8-32 x 1
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 3206344 A B Spring
34 3206345 A B Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 A B Screw-gear/cam,6-20 x 0.437
36 3206347 A B Cover-ice maker,complete
37 5303320544 A B Data Sheet,ice maker
38 5303207445 A B Envelope-data sheet
39 # 3206358 A B Harness-wiring,ice maker
40 5305877995 A B Sealing Strip
41 5308000039 A B Screw,hex wshr hd ,8-32CA x 0.500 ,srratd head
43 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B Clamp,nylon ,.75 OD tube
45 218843800 A B Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
45* 5303207328 A B Screw,hex wshr hd ,8-15A x 1
46 5303001193 A B Clamp-inlet tube,metal
47 5308000205 A B Adapter-water sply,straight
48 5308000200 A B Nut,7/16 x 20 ,nylon
49 5303001147 A B Plug-harness hole,(2)
52 215456100 A B Tube-water inlet
55 # 218720300 A B Valve-water,120 V 60 Hz ,flow restricter
55* 5303015102 A B Cap-water valve
59 5303001191 A B Sleeve-tube insert
60 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
61 218721500 A B Bracket-leveling,ice maker
62 215230500 A B Screw-bracket mtg,pan head ,8-32T x 0.375
62 218737900 A B Screw-IM mtg brkt,hex hd ,#8-32 x 3/8
64 5303001549 A B Clamp-copper tube,steel
* 5303212918 A B Container-ice
