# = Fast-moving Parts 5 08/00
* = Non-Illustrated Parts
FRT22IRSH Publication No.
5995342614
A = FRT22IRSH (FRT22IRSHB4)
B = FRT22IRSH (FRT22IRSHK4)
POS. NO PART NO DESCRIPTION
1 215937600 A B Shroud-evap fan mtg
5 # 5303292398 A B Fan Blade
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 5304416067 A B Cover-evap coil
11 5303208309 A B Plug-hole,factory test
13 # 218661700 A B Motor-evap fan
13* 215474201 A B Washer,"slinger" ,nylon ,evap fan shaft
14 5303292397 A B Bracket-motor mtg,rear
15 215812200 A B Light Bulb/Lamp,25W
15A 218708700 A B Light Bulb/Lamp,crisper light ,(2)
16 5308000129 A B Socket-light/lamp
16A 5303299157 A B Socket-light/lamp,crisper light
17 5304415955 A B Trough-drain
18 218980401 A B Support-evap cover,(2)
22 215774918 A B Plug-button,black ,upr hinge holes
23 215266301 A B Tube-drain,w/seal ring
24 5303207353 A B Seal Ring,drain tube
25 5303292412 A B Spout-drain tube
28 5303289062 A B Bolt-roller adj,hex head ,5/16-24 x 7/8
29 215314301 A B Washer,.40 x .75 x .06 ,nylon
30 218993701 A B Bracket-lower hinge,RH ,w/hinge pin
30* 218979601 A B Tapping Plate,lower hinge
30* 218979701 A B Tapping Plate,lower hinge
34 218737000 A B Washer-ctr hnge pin
35 218220103 A B Bracket-ctr hinge,black
36 218971101 A B Pin-center hinge
37 5303321083 A B Trim-cabinet corner,black
38 218215244 A B Bracket-upper hinge, with closer, black
38* 5304403492 A B Tapping Plate,upper hinge ,(2)
40 5303323268 A B Cover-upper hinge,black
41 5303294246 A B Grommet-shelf mtg,1.25" long
41* 5303294247 A B Grommet-shelf mtg,.69" long
43 218615300 A B Roller Assy,front ,(2)
43* 5308017044 A B Screw-roller mtg, spcl ind hex hd, 5/16-18(23)x7/8
44 218738300 A B Roller Assy,rear ,(2)
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
47 218233300 A B Channel-shelf mtg,side ,(2)
48 218877701 A B Channel-shelf mtg,center
52 215454600 A B Tube-water,ice mold fill ,elbow
58 5308002748 A B Screw, hex wshr hd, 8-15A x 0.500, special
59 218188000 A B Screw, pan hd, 10-32 x 0.625, hinge/mullion, thrd forming
60 218362500 A B Screw,hex washer head ,8-18AB x 1.250
65 5303001361 A B Pin-mounting,push-in ,plastic
72 218359612 A B Grille/Kickplate,black
74 215423500 A B Shield-light,frzr
78 5303274237 A B Screw-bracket, hex wshr hd, 8-32CA x 0.500
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B Bracket-connector
89 215741407 A B Cover-machine compt,w/caution label
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
93 218362603 A B Plug-grille,black
94 5303319993 A B Cover-air duct
94* 218044800 A B Seal-air duct cover
95 218663101 A B Gasket-air duct cvr
96 215775901 A B Cover-fan access
98 215099718 A B Plug-button,black
100 5303288973 A B Support-pan cover
107 218835902 A B Shield-light,crisper
108 218834202 A B Cover-wiring,crisper light
114# 5303299156 A B Switch-light/lamp,black
* 215848000 A B Spacer-air channel
* 5303321321 A B Paint,touch-up ,black
* 5308016571 A B Plug-button,cab liner holes
* 08006983 A B Spacer-divider
CABINET
