# = Fast-moving Parts 7 08/00
* = Non-Illustrated Parts
FRT22IRSH Publication No.
5995342614
SHELVES
A = FRT22IRSH (FRT22IRSHB4)
B = FRT22IRSH (FRT22IRSHK4)
POS. NO PART NO DESCRIPTION
1 5303299280 A B Mullion,black
5 # 218752300 A B Heater-mullion
6 218845601 A B Tapping Plate,mullion mtg ,(2)
7 218907501 A B Top Panel-refr,HASC
7* 218493100 A B Screw,hex washer head ,8-18AB x 1-3/4
7* 218989901 A B Nut-anchor,divider
8 218909707 A B Divider,styrofoam ,w/foil tape
8* # 218965601 A B Harness-wiring,control/divider
9 215058300 A B Bottom Panel-frzr
11 5304409141 A B Shelf-freezer,w/trim
11* 5303299664 A B Spacer-shelf
12 218634902 A B Deflector-air,"paddle"
12* 215363801 A B Spacer-air deflectr
12* 215363901 A B Washer-air deflectr
12* 218634800 A B Spacer-air deflectr
13 218629900 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 5303001179 A B Light Bulb/Lamp,40 W
16A# 218906801 A B Socket-light/lamp
17 215932906 A B Control Box
17* 5308016567 A B Nut-anchor
18 5304414917 A B Knob-temp control,refr
18A 5304414918 A B Knob-temp control,(damper)
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5304402184 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22 218660701 A B Tube,insulator ,plastic ,on temp sensor
23 # 215846606 A B Timer-defrost, 60 Hz, 120 V, 10 hour/30 min
23* 215277000 A B Cover-defrost timer,top
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
23* 5303289058 A B Shield-defrost timr,btm
25 215216649 A B Cover-crisper pan, with beam, trim, humid cont
25A 5303308349 A B Trim-crisper cover
25B 5303307881 A B Control-humidity
26 5303292386 A B Pan-crisper,(2)
28 215341200 A B End Cap-shelf,protector
31 5303304632 A B Pan-meat
34 5303212918 A B Container-ice
36 215406115 A B Shelf-"Spill-Safe",fixed ,teal graphics
42 215002301 A B Hanger-pan/tray,LH
42* 215002401 A B Hanger-pan/tray,RH
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
46 218278401 A B Front-crisper pan,(2)
47 218390564 A B Insert-pan cover,glass ,teal graphics
51 215132809 A B Duct-meat keeper,upper
51* 215133200 A B Insulation-air duct,rear
51* 215133300 A B Insulation-air duct,front
52 215132901 A B Control-damper,meat kpr duct
52* 215133000 A B Damper-air,meat kpr duct
54 215133100 A B Duct-meat keeper,lower
59 218188000 A B Screw,pan hd ,10-32 x 0.625, hinge/mullion,thrd forming
59* 215069518 A B Cap-mullion screw,black
59* 218188500 A B Screw-mullion mtg, LH,10-32 x 0.750,thrd forming
67 218278701 A B Front-meat pan
77 5303001216 A B Washer-nylon,3/16 x 5/8 OD
81 5303001380 A B Screw,truss head ,8-10 x 1.625
119 215132700 A B Cap-air duct
120 218019201 A B Seal-refr top
121 215364001 A B Cable-damper contrl
121* 215209400 A B Nut,push-on ,damper cable
122 218561202 A B Block-air deflector,RH
122 218561204 A B Block-air deflector,LH
123 215005100 A B Screw-roller/hanger,8-10 x 0.438
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in
* 215339100 A B Seal-divider throat
* 215339900 A B Clip-shelf
* 215359900 A B Seal-divider front
* 215848000 A B Spacer-air channel
