# = Fast-moving Parts 9 08/00
* = Non-Illustrated Parts
FRT22IRSH Publication No.
5995342614
SYSTEM
A = FRT22IRSH (FRT22IRSHB4)
B = FRT22IRSH (FRT22IRSHK4)
POS. NO PART NO DESCRIPTION
1 218787700 A B Condenser
1* 5303208866 A B Spacer-cond tube,black
1* 5303289026 A B Spacer-tube
1* 5304406721 A B Spacer-cond tube,round ,5/8 OD x .81"lg
2 5303289029 A B Clip-cond mtg,(4)
4 # 218944001 A B Drier-filter,R134a System
5 # 218965601 A B Harness-wiring, control/divider
5* # 218463600 A B Wiring Harness,crisper lights
6 # 218966001 A B Wiring Harness,machine compt
7 215459201 A B Cord-electric power
8 218803400 A B Cover-wiring
13 # 218168602 A B Heat Exchanger,suction line
14 # 5317842502 A B Heater-defrost
15 # 218956001 A B Evaporator,bundy
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 5304415939 A B Insulator-evap,plastic
18 218979801 A B Block-evap coil,styrofoam insul ,RH
19 218631200 A B Tube,rubber
20 218979501 A B Block-evap coil,styrofoam insul ,LH
20A 5303292405 A B Insulation Plug,LH
21 # 218969902 A B Thermostat-defrost
22 218811100 A B Base-compressor mtg,(drain pan)
23 218513300 A B Grommet-compr mtg,(4)
25 218773500 A B Screw-compressor mtg,hex washer hd, 10Bx11/4
29 # 218374517 A B Compressor,R134a ,w/o electricals
30 # 218721101 A B Starter/Overload Assy
32 218740800 A B Clamp,elec cont mtg ,compressor
41 5303001343 A B Screw,hex washer head ,8-15A x 0.500
43 215174700 A B Clamp-service cord, strain relief, galv steel
43* 5303001199 A B Clamp-wiring harness, strain relief, galv steel
43* 5308000133 A B Clamp,nylon ,.625 ID
45 218769200 A B Screw,hx wshr hd spec ,#6-32 x .5
45* 5300141713 A B Screw,hex wshr hd ,8-32 x 0.625 ,spec
45* 5303210353 A B Screw,hex wshr hd ,8-32CA x .5
54 5303289027 A B Rail-cabinet base,rear
54* 218754500 A B Screw,hex hd ser wshr ,8-18 x 0.375
54A 5303289311 A B Rail-compr support
54B 5303289292 A B Rail-cabinet base,front
55 # 218909901 A B Capacitor-run,220 VAC ,15 microfarad
56 218769300 A B Insert-compressor mtg
57 218247300 A B Clip-wiring harness
58 215004600 A B Screw-cond fan mtr,hx serr wshr hd, 8-36 x 7/16, (2)
59 5303289031 A B Shroud-cond fan mtr
59* 215226700 A B Seal-foam,cond fan shroud
60 # 215501901 A B Motor-condenser fan
61 5303289032 A B Blade-cond fan
61* 215004700 A B Nut,speed
61* 215004800 A B Grommet-silencer
* 5303917214 A B Hot Tube Repair Kit,Service
To Next Page
