# = Fast-moving Parts 11 09/00
* = Non-Illustrated Parts
GLRSF266J Publication No.
5995343067
A = GLRSF266J (GLRSF266JW1)
B = GLRSF266J (GLRSF266JD1)
C = GLRSF266J (GLRSF266JB1)
POS. NO PART NO DESCRIPTION
2 215028605 A B C Knob-damper control
5 # 5308000010 A B C Fan Blade,red
7 5308000124 A B C Ring-fan orifice
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303205118 A B C Bracket-motor mtg,front
12 215809600 A B C Diffuser-air
13 # 215426200 A B C Motor-evap fan
13* 215474201 A B C Washer,"slinger" ,nylon ,evap fan shaft
14 5303205119 A B C Bracket-motor mtg,rear
15 5303001179 A B C Light Bulb/Lamp,40 W
16 # 5303289050 A B C Socket-light/lamp
17 5303296805 A B C Control Box,refr
17A 5303296581 A B C Control Box,frzr
17A* 215188300 A B C Screw-control box mtg,hex head ,8-15A x 1.0,refr/frzr
18 5303308568 A B C Knob-temp control,frzr
20 5304411663 A B C Label-control box,refr
20A 5303308611 A B C Label-control box,frzr
21 # 5303300027 A B C Control-temperature
22 5303319683 A B C Housing-temp sensor,plastic
22* 218731102 A B C Tube,insulator ,PVC ,white ,on temp sensor
23 # 215846602 A B C Timer-defrost,60 Hz ,120 V ,8 hour/30 min
23* 215277000 A B C Cover-defrost timer,top
23* 5303001259 A B C Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
23* 5303289058 A B C Shield-defrost timr,btm
41 5308000039 A B C Screw,hex washer head ,8-32CA x 0.500 ,srrtd hd
41* 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg
53 215809512 A B C Box-damper control
65 5303001361 A B C Pin-mounting,push-in ,plastic
75 218465101 A B C Shield-light,refr
76 218225800 A B C Cover-light socket
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C Bracket-connector
111 5303297842 A B C Wireway,frzr
114# 5303289051 A B C Switch-light/lamp,white
115 215011505 A B C Damper Assy,w/seal
116 215011400 A B C Seal-damper,foam
125 215334201 A B C Switch-auger kill,white
137 218904602 A B C Filter-water,carbon ,with o’ ring
138 218893301 A B C Cup-water filter
138* 218904301 A B C O-ring,wtr filter cup
139 218893201 A B C Housing-wtr filter
140 218518700 A B C Elbow-water tube
141 218832401 A B C Valve-water,dual solenoid ,115 V ,w/nut
141* 215290100 A B C Screw-solenoid valve,hx hd-slot wshr ,12-24 x 3/4
143 218696700 A B C Heater-water filter
* 218646000 A B C Wiring Harness,filter heater
CONTROLS
