Frigidaire GLRSF266J - Dispenser Parts List

# = Fast-moving Parts 15 09/00
* = Non-Illustrated Parts
GLRSF266J Publication No.
5995343067
A = GLRSF266J (GLRSF266JW1)
B = GLRSF266J (GLRSF266JD1)
C = GLRSF266J (GLRSF266JB1)
POS. NO PART NO DESCRIPTION
1 218832301 A B C Tube-water inlet,inlet valve ,to filter
1* 218949201 A B C Tube-water inlet,formed ,plastic ,dispenser
1A 218859901 A B C Tube-water inlet,inlet valve ,to filter
2 218505301 A - - Deflector-ice disp,white
2 218505302 - B - Deflector-ice disp,almond
2 218505303 - - C Deflector-ice disp,black
3 # 215484300 A B C Heater-door housing
4 218852401 A - - Housing-dispenser,white
4 218852402 - B - Housing-dispenser,almond
4 218852403 - - C Housing-dispenser,black
7 # 218284800 A B C Switch-actuator,micro
8 218874901 A B C Module-dispenser
10 218209800 A B C Spring,dispenser door
12 218836201 A - - Knob-selector,white
12 218836202 - B - Knob-selector,almond
12 218836203 - - C Knob-selector,black
12A 218925401 A - - Knob-selector,white
12A 218925402 - B - Knob-selector,almond
12A 218925403 - - C Knob-selector,black
12A* 218925501 A B C Spring-knob
14 218903730 A - - Label-module cover,white
14 218903744 - B - Label-module cover,almond
14 218903732 - - C Label-module cover,black
15 218284900 A B C Light Bulb/Lamp,4 W ,115 V
16 215284900 A B C Socket-light/lamp
17 215794400 A B C Screw,#6 x 1/4
17A 215840700 A B C Screw,truss head ,6-20 x 3/8
17A* 215923400 A B C Washer-flat
23 5303297844 A - - Drip Tray,white
23 5303297845 - B - Drip Tray,almond
23 5303299660 - - C Drip Tray,black
24 218921301 A - - Actuator,white
24 218921302 - B - Actuator,almond
24 218921303 - - C Actuator,black
26 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
27 218432600 A B C Cam-slide
27A 218814901 A B C Rocker-switch
28 218906201 A - - Cover-module,white
28 218906202 - B - Cover-module,almond
28 218906203 - - C Cover-module,black
30 215753600 A B C Door Assy-ice chute,w/gasket,insul
33 # 218870201 A B C Heater-disp throat
35 # 218740005 A B C Heat Motor,115 V
36 218906001 A B C Cover-selector sw
38 # 218905901 A B C PC Board
38A# 218479900 A B C Switch-micro,single pole ,double throw
38B# 218835401 A B C Switch-micro,single pole ,single throw
39 218284600 A B C Wire-ice door
40 218284500 A B C Yoke-heat motor
41 215917800 A B C Spring-actuator
43 215760300 A B C Screw,#4 x 3/8
49 215794000 A B C Bracket-heat motor
56 218434300 A B C Screw-micro switch,pan head ,4-24 x 9/16
56A 218927401 A B C Screw,pan head ,4-24 x 1.125 ,microswitch mtg
82 215296300 A B C Screw,plask h/l ,#6 x 3/8
84 218906401 A B C Switch-membrane
85 218948201 A B C Transformer-dispenser
* 218863111 A B C Wiring Harness,disp
DISPENSER
