# = Fast-moving Parts 3 09/00
* = Non-Illustrated Parts
GLRSF266J Publication No.
5995343067
FREEZER DOOR
A = GLRSF266J (GLRSF266JW1)
B = GLRSF266J (GLRSF266JD1)
C = GLRSF266J (GLRSF266JB1)
POS. NO PART NO DESCRIPTION
1 # 215734313 A B - Gasket-frzr door,white ,magnetic
1 # 215734323 - - C Gasket-frzr door,black ,magnetic
5 5303288950 A B C Support-door rack,RH/LH
6 5303323484 A B C Support-door rack,white ,LH
6A 5303323485 A B C Support-door rack,white ,RH
8 218807028 A B C Rack-door,w/end caps
8A 215474052 A B C Rack-door
9 218510401 A B C Panel-inner door,frzr
11 5303918162 A - - Panel-ext frzr door,white ,w/foam insulatn
11 5303918165 - B - Panel-ext frzr door,almond ,w/foam insulatn
11 5303918164 - - C Panel-ext frzr door,black ,w/foam insulatn
13 5303289522 A B C Door Stop
18 218762701 A - - Handle-door,white
18 218762704 - B - Handle-door,almond
18 218762703 - - C Handle-door,black
21A 218578600 A B C Screw-door stop mtg,phl truss hd ,10-16 x 3/4
22A 215615300 A B C Bushing-door,bronze
23 218958100 A B C Screw,flat hd ,#8-32D x 1/2
37 215867064 A - - Trim-handle,white ,upper ,w/dec gold band,and snap lock
37 215867065 - B - Trim-handle,almd ,upper ,w/dec gold band,and snap lock
37 218811628 - - C Trim-handle,black ,upper ,w/gold band ,and snap lock
37A 215867061 A - - Trim-handle,white ,lower ,w/dec gold band,and snap lock
37A 215867062 - B - Trim-handle,almd ,lower ,w/dec gold band,and snap locks
37A 218811627 - - C Trim-handle,black ,lower ,w/gold band ,and snap lock
37A* 215782300 A B C • Lock-handle trim,snap-in
37A* 218676003 A B C • Band-decorative,gold
47 218922901 A B C Wiring Harness,frzr door
58 218781100 A B C Screw,pan head ,8-18 x 0.625
68 218495200 A B C Chute-ice
140 218922801 A B C Elbow-water tube
141 218929601 A B C Tool-Push Connector
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)
