11
DOOR REMOVAL
4. Make sure you removed the
top doors.
5. With the bottom doors closed, remove
the center hinge unscrewing the 3
screws fixing them to the cabinet.
6. Carefully remove the door by
opening it and pushing it upward.
Center Hinge Removal
7. Repeat this procedure for both
bottom doors.
NOTE
To gain access to center hinge, unscrew
the 3 hinge screws and remove the hinge.
8. To reinstall the doors, reverse
the procedure.
