Technical Specifi cations
• IEEE802.11n, compatible with
IEEE802.11g/b
• Up to 450Mbit/s (gross); the user data
rate that can actually be achieved is
somewhat below the specifi ed values.
• WPA, WPA2 (802.11i)
• Ethernet: LAN port over RJ45 socket
(gigabit Ethernet, 10/100/1000 Base-T)
• Total power consumption: approx. 5W
• WLAN: 2.4GHz max. 100mW
• 230V, 50Hz A/C
• 0°C to +40°C
• Dimensions: 101mm x 76mm x 76mm
• Weight: approx. 120g
• Antennas: three integrated antennas
System Requirements
• Wireless access point compliant with
IEEE802.11b/g/n, 2.4GHz, automatic IP
address assignment (DHCP)
• The wireless access point must support
the encryption standard WPA or WPA2.
• For expanded Mesh WiFi functions:
FRITZ!Box with FRITZ!OS version 6.90 or
higher
• For initial confi guration with WPS: WPS-
compliant wireless access point
• For initial confi guration without WPS:
computer with wireless LAN that supports
the WPA encryption standard
• For the fi rst confi guration of WLAN: If
the MAC address fi lter is active in the
wireless access point, the MAC address
of the FRITZ!WLANRepeater must be
entered as an exception in the MAC
address fi lter.
LEDs and Buttons
The LEDs show the operating status:
on fl ashing
Quality of the wireless radio
signal
Connection to the wireless access point is
interrupted
Power
FRITZ!WLANRepeater 450E is
ready for operation
• The FRITZ!WLANRepeater 450E is being
started.
• Updating FRITZ!OS
WLAN
Wireless LAN function enabled. • WPS in progress; flashes fast: WPS was
aborted
• Enabling Mesh WiFi
• Adopting the wireless LAN settings
LAN
Network device connected
all
Loading factory settings
Operate the FRITZ!WLAN Repeater 450E using the WPS button:
Press the WPS button
Initiate WPS / Enable Mesh WiFi
1second
Connect with another access point
6seconds
Factory Settings
15seconds
