Fritz! Fon WLAN 7390 User Manual

110
WLAN Connection Is Not Established
5. Click the “Apply” button.
6. Remove the network cable and try again to establish
a wireless connection in the desired frequency band.
10.3 WLAN Connection Is Not Established
Comparing the Security Settings for WLAN
Make sure that the WLAN security settings registered in
the FRITZ!Box agree with the security settings of the WLAN
adapter.
Here is how to view the WLAN security settings of the
FRITZ!Box and print them out.
1. Connect the FRITZ!Box to a computer using a network
cable. Proceed as described in the section “Connect-
ing Computers to the LAN Port” from page 16.
2. Start a web browser.
3. Enter fritz.box
in the address field.
4. Select the “WLAN / Security” menu.
5. Click the “Apply” button.
A window is displayed with the WLAN security set-
tings. Print out the page by clicking the “Print Page”
button.
6. Remove the network cable and check the configura-
tion of the WLAN adapter in the printout. Try again to
establish a connection.
Testing the WLAN Connection without Security
Settings
Disable the WLAN security settings to test whether a WLAN
connection between the FRITZ!Box and the WLAN adapter
is possible at all.
1. Connect the FRITZ!Box to a computer using a network
cable. Proceed as described in the section “Connect-
ing Computers to the LAN Port” from page 16.
