Friulinox Cube Series - Installation Checklist and Procedures

“go to TABLE OF CONTENTS”
FRIULINOX ALI GROUPS.R.L. A SOCIO UNICO 16
Via Treviso,4 - 33083 Taiedo di Chions (PN) -Italy
Service Manual
5. INSTALLATION CHECK LIST
Refrigerated cabinets installation checklistrev0 of 17/11/2017
Customer name
Installation date
Address
Installer technician
City
Installer company
Country
Model
Tel. no.
Serial number
E-mail address
Power supply voltage
Reference contact
Checks
Notes
Check the package status and integrity

Check for aesthetic defects

Remove the protective film from all surfaces

Cabinet installed on wheels?
YES □
NO □
Condensing unit on the machine?
YES □
NO □
Check that the evaporator cover is correctly
fastened with belt

Indicate the available space around the storage cabinet:
left side - minimum 50 (mm)
…………..
right side - minimum 50 (mm)
…………..
front (mm)
…………..
back - minimum 50 (mm)
…………..
above - minimum 500 (mm)
…………..
Indicate the equipment around the cabinet (oven/refrigerator/blast chiller/refrigerated
counters/worktable/dishwasher/wall/free/other)
left side
…………………………………………………………………………………………………………………….
right side
…………………………………………………………………………………………………………………….
front
…………………………………………………………………………………………………………………….
back
…………………………………………………………………………………………………………………….
above
…………………………………………………………………………………………………………………….
Level equipment (recommended inclination of 2%
to the front)

Electrical connection
Make sure that the power socket is equipped
with a 30mA thermal breaker

Connect the single-phase models to the power
socket via Shuko plug (already installed)

Only for water-condensation units (WL)
Check the seal of the hydraulic connections

Indicate the condenser inlet water pressure - max
5 (bar)
…………..
Indicate the condenser inlet water temperature -
max 30(°C)
…………..
Calibrate the pressure valve at 13 - 15 bar (WL
version only)

