8.2. Door opening inversion
1. Loosen the central screw closing the front panel using a
screwdriver.
2. With star-tipped screwdriver, loosen the two fixing
screws of the upper hinge.
3. Remove the door by lifting it from the lower hinge.
With start-tipped screwdriver, loosen the two locking
plate screws on the upper side of the door.
4. Remove the upper hinge from the seat, together with
the spring.
5. Using the Ø 7 tip screwdriver, drill the upper hinge as
shown in the figure to open the hole on the left.
6. Replace the right spring with the left spring,
recognisable by the anti-clockwise direction of the
spiral, inserting it into the hinge.
