3 | Initial start-up with settings wizards
38 B1820023_en | Service handbook Lambdatronic H 3200 - T4e
3.2 General information about the settings wizard
A wide variety of setting wizards are available to start-up the boiler system. A small selection of these can be
found on the “Customer” operating level in the “Quick menu”; the rest are only on the “Service” operating level.
The settings wizards can be used to set various sections of the boiler system (boiler, lambda probe, hydraulic
system, etc.) with guided queries of the controller.
The following settings wizards are available for specific systems. Because they are interdependent, the
sequence is automatically determined by the controller.
Icon Designation
Switching on for the first time
Queries are made regarding language, facility number, date and time
Boiler
Setting for boiler type, boiler output, fuel, return temperature control and boiler-specific options (ignition, filter,
etc.)
Lambda probe
Selection and calibration of the type of sensor used
Feed system
Selection of the existing discharge system (only for boilers with automatic loading)
Hydraulic system
Selection of the hydraulic system (hydraulic system 1, 2, 3, etc.)
Additional components
Selection and activation of the existing load and control components (heating circuits, DHW tank, solar,
difference controller, etc.)
Heating up
Initial filling of the pellet container for pellet and dual fuel boilers;
filling of the discharge screw and defining the loading times for the start process for wood chip boilers
Connect
Setting parameters required for the boiler to use the “froeling-connect.com” online control (IP address,
display password, etc.)
Heating up program
Activation and selection of a heating up program.
