Synergic control panel
General The functions on the control panel are all arranged in a logical way. The various
welding parameters can easily be selected using buttons and can just as easily be
-
altered using buttons or the adjusting dial
-
displayed on the digital display during welding
The synergic function ensures that all other welding parameters are adjusted
whenever an individual parameter is changed.
NOTE!
Due to software updates, you may find that your device has certain functions
that are not described in these operating instructions or vice versa.
Individual illustrations may also differ slightly from the actual controls on your
device, but these controls function in exactly the same way.
The power source uses the Synergic control panel and certain general items of
data such as sheet thickness, filler metal, wire diameter and shielding gas to cal-
culate the best welding parameters. As a result, stored knowledge is available at
all times. All the parameters can be adjusted manually. The Synergic control pan-
el also allows parameters to be set manually.
Safety
WARNING!
Danger from incorrect operation and work that is not carried out properly.
This can result in serious personal injury and damage to property.
▶
All the work and functions described in this document must only be carried
out by technically trained and qualified personnel.
▶
Read and understand this document in full.
▶
Read and understand all safety rules and user documentation for this device
and all system components.
