Inserting the
wirespool
CAUTION!
Risk of injury due to springiness of spooled wire electrode.
▶
While inserting the wirespool, hold the end of the wire electrode firmly to
avoid injuries caused by the wire springing back.
CAUTION!
Risk of injury from falling wirespool.
▶
Make sure the wirespool sits securely on the wirespool holder.
CAUTION!
Risk of injury and material damage if the wirespool topples over because the
locking ring has been placed the wrong way around.
▶
Always position the locking ring as shown in the diagram on the left.
55
EN
