28
VR 1500 / VR 1550: connect the interconnecting hosepack to the wirefeeder
VR 1500 - 11 / 12 / 30: Connecting the interconnecting hosepack to the wirefeeder
A Interconnecting hosepack; wirefeeder end
R red
B blue
A Interconnecting hosepack; wirefeeder end
C 2nd power cable (optional)
R red
B blue
(10)(11) (9)
(1) (3)
B
R
A
(10)(11) (9)
(4)
(3)
B
R
(1)
A
C
