FrontLine ROP16 - Page 18

Instruction Manual
BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT
18
Connecting Subsystem
(Energy Absorbing Lanyard
Shown)
A)
B)
C)
D)
E)
F)
Free Fall - 6ft. (1.8m)
Max. (per ANSI Z 359.11)
Deceleration Distance
Total Fall Distance Free
Fall (D) + Deceleration (E)
Working Level Shown
Lower Level or Obstruction
FIGURE 3
