8
RUNNING YOUR CAR
5. TUNING THE STEERING TRIM
6. TUNING THE THROTTLE TRIM
7. TO TUNE THE STEERING DUAL RATE CONTROL DIAL
THROTTLE TRIM
8. STEERING/THROTTLE REVERSE
This function is used to adjust each channels direction of movement in relation to
it’s input .The ST.REV/TH.REV switches are the reverse buttons for CH1 and CH2.
If the switch is up it indicates reverse, down indicates normal.
STEERING D/R KNOB:
The dial marked ST-DR is for servo travel adjustment.
You should adjust this to give maximum steering without straining the servo.
When rotated fully anticlockwise zero rate is applied.
Turn clockwise to apply dual-rate percentage.
When adjusting the DR, the LED light bar will display the DR value.
After 5 seconds the LED light bar will return to display the battery level.
STEERING D/R
STEERING
STEERING TRIM KNOB:
The ST-TRIM knob is used to adjust the trim of the steering so that the wheel are centered
and the vehicle tracks straight.
When you adjust the ST-TRIM, the LED will display the ST-TRIM value. After the adjustment is
completed for 5 seconds, the LED will return to indicate the battery level.
THROTTLE TRIM KNOB:
The TH-TRIM knob is used to adjust the throttle trim when the throttle stick is at neutral
position. It is typically used to adjust the brakes.
When you adjust the TH-TRIM, the LED will display the TH-TRIM value. After the adjustment is
completed for 5 seconds, the LED will return to indicate the battery level.
