Operating characteristics and performance
2-4 Performance with current at 100%
Table 2-11 MCCB internal resistance and power consumption
Type Rated current
(A)
Internal
resistance
(m
:
/phase)
Power
consumption
(W/3-phase)
BW32AAG
BW32SAG
BW32AFC
3 101.0 2.7
5 39.3 2.9
10 11.4 3.4
15 5.8 3.9
20 3.8 4.6
30 2.3 6.2
32 2.1 6.4
BW32SBG 3 116.0 3.1
5 50.5 3.8
10 13.8 4.1
15 6.5 4.4
20 4.1 5.2
30 2.8 7.6
32 2.8 8.6
BW50AAG
BW50EAG
BW50SAG
BW50AFC
5 39.3 2.9
10 11.4 3.4
15 5.8 3.9
20 3.8 4.6
30 2.3 6.2
32 2.1 6.4
40 1.7 8.2
50 1.4 11.0
BW50RAG 10 10.9 3.3
15 5.3 3.6
20 3.3 4.0
30 1.8 4.9
32 1.7 5.2
40 1.2 5.8
50 1.0 7.5
BW50HAG 15 14.0 9.5
20 11.8 14.2
30 5.0 13.5
40 2.7 13.0
50 2.1 15.8
BW50EBG
BW50SBG
3 116.0 3.1
5 50.5 3.8
10 13.8 4.1
15 6.5 4.4
20 4.1 5.2
30 2.8 7.6
32 2.8 8.6
40 1.7 8.2
50 1.5 11.3
BW63EAG
BW63SAG
BW63RAG
60 0.9 9.7
63 0.9 10.7
BW63EBG
BW63SBG
60 1.1 11.9
63 1.1 13.1
BW100AAG
BW100AFC
60 0.9 9.7
63 0.9 10.7
75 0.7 11.8
100 0.6 18.0
BW100EAG 50 1.0 7.5
60 0.9 9.7
63 0.9 10.7
75 0.7 11.8
100 0.6 18.0
Type Rated current
(A)
Internal
resistance
(m
:
/phase)
Power
consumption
(W/3-phase)
BW125JAG
BW125RAG
BW125HAG
15 14.0 9.5
20 11.8 14.2
30 5.0 13.5
40 2.7 13.0
50 2.1 15.8
60 1.5 16.2
75 1.1 18.6
100 0.8 24.0
125 0.7 32.8
BW250EAG
BW250JAG
BW250RAG
BW250HAG
125 0.56 26.3
150 0.49 33.1
160 0.39 30.0
175 0.39 35.8
200 0.31 37.2
225 0.24 36.5
250 0.21 39.4
BW400EAG
BW400SAG
BW400RAG
BW400HAG
250 0.25 47.0
300 0.21 57.0
350 0.19 70.0
400 0.18 86.4
BW630EAG
BW630RAG
BW630HAG
500 0.117 88.0
600 0.097 105.0
630 0.097 116.0
BW800EAG
BW800RAG
BW800HAG
700 0.087 128.0
800 0.070 134.0
BW1000RAE 400 0.062 29.8
500 0.062 46.5
600 0.062 67.0
700 0.062 91.1
800 0.062 119.0
900 0.062 150.7
1000 0.062 186.0
BW1250RAE 500 0.04 30.0
600 0.04 43.2
700 0.04 58.8
800 0.04 76.8
1000 0.04 120.0
1200 0.04 172.8
1250 0.04 187.5
BW1600RAE 700 0.022 32.3
800 0.022 42.2
900 0.022 53.5
1000 0.022 66.0
1200 0.022 95.0
1400 0.022 129.4
1500 0.022 148.5
1600 0.022 169.0
Type Rated
current
(A)
Fixed device Additional power / pole (W)
R/pole
(m
:
)
P/pole
(W)
Plug-in Ammeter
module
Transfo.
module
BX100 40 0.84 1.34 0.2 0.1 0.1
100 0.468 4.68 1 0.2 0.2
BX160 160 0.36 9.16 2.6 0.5 0.5
BX250 100 0.27 2.73 1.6 0.2 0.2
250 0.28 17.56 6.3 1.3 1.3
BX400 400 0.12 19.2 9.6 2.4 2.4
BX630 630
(1)
0.1 39.69 19.49 5.95 5.95
BX800 800 0.026 15 –
BX1000 1000 0.026 22 –
BX1250 1250 0.026 44 –
BX1600 1600 0.026 74 –
(1) The power loss values for the withdrawable circuit breakers are given for 570 A.
