FUNCTION CODES
Chap 5
■ Drive control
The FRENIC-Ace runs under any of the following drive controls. Some function codes apply exclusively to the
specific drive control, which is indicated by letters Y (Applicable) and N (Not applicable) in the “Drive control”
column in the function code tables given on the following pages.
Abbreviation in “Drive
control” column in function
code tables
Control target (H18) Drive control (F42)
V/f
Speed
(Frequency for V/f and PG V/f)
0,2: V/f control
1: Dynamic torque vector control
PG V/f
3: V/f control with speed sensor
4: V/f control with speed sensor and
auto torque boost
w/ PG 6: Vector control with speed sensor
Torque control Torque 6: Vector control with speed sensor
PM Speed
15: Vector control without speed sensor
nor pole position sensor
For details about the drive control, refer to the description of F42 “Drive control selection 1.”
The FRENIC-Ace is a general-purpose inverter whose operation is customized by frequency-basis
function codes, like conventional inverters. Under the speed
control, however, the control
target is a motor speed, not a frequency, so convert the frequency to the motor speed according to the
following expression.
