5.2 Function Code Tables
Control method and Data setting range
9005: Analog terminal [C2] input signal “C2”
9006: Reserved
9007: Reserved
9008: Analog terminal [C1] input signal (V3 function) “V3”
9010: UP/DOWN value “UP/DOWN”
Customizable logic Step 1 to 14 function code is assigned as follows: Setting value is the same as U01 to U05.
Control method and Data setting range
Customizable logic
(Output selection)
Output signal 1
0: Invalid
1 to 260: Output of Step 1 to 260 “S001” to “S0260”
Customizable logic
(Function selection)
Output signal 1
0 to 172 (1000 to 1172): same as E98, but 19 and 80 cannot be selected.
241 to 245 (1241 to 1245): User-defined alarm 1 to 5 “CA1” to “CA5”
8001 to 8020: The value with 8000 added to E61
Customizable logic: Timer
monitor (Step selection)
0: Monitor disable
1 to 260: Step 1 to 260
Customizable logic
(The coefficients of the
approximate formula)
(Mantissa of KA1)
Customizable logic
Output monitor
(Step selection)
0: Monitor disable
1 to 260 : Step 1 to 260
Customizable logic
Output monitor
(Display unit selection)
Same as J105 (0 cannot be set.)
Task process cycle setting
0: Auto (Automatic selection from 1, 2, 5, 10, or 20 ms based on number of
steps)
1: 1 ms (Up to 10 steps)
2: 2 ms (Up to 20 steps)
5: 5 ms (Up to 50 steps)
10: 10 ms (Up to 100 steps)
20: 20 ms (Up to 260 steps)
127: Multi-task (Multiple cycles can be set up to 20 steps)
