Fuji Xerox ApeosPort C6570 User Manual

-39-
iv Problem Solving
(2) Pull the lever [A3].
(3) While holding the lever [A3], remove the jammed paper.
(4) Return the lever [A3] to the original position.
2. Close the upper left cover.
Inside Lower Left Cover
1. While lifting up the release lever, open the lower left
cover.
Note
When High Capacity Feeder is installed, hold the han-
dle and fully move the unit to the left.
2. Remove the jammed paper.
3. Close the lower left cover.
A3
