10 Maintenance
208
2
Grip the handles of the toner cartridge and pull it out of the main unit slowly.
3
Grip the orange handle of the drum cartridge and pull it out of the main unit.
Place the removed drum cartridge on a level surface.
When removing the drum cartridge, be careful not to drop it on the floor.
Be careful not to touch the toner attached to the cartridge.
4
Clean the LED printhead.
For how to clean, refer to "Cleaning the Interior (LED Printheads)" (P.210).
5
Take the new drum cartridge out of the box, and insert the used drum cartridge into the
supplied plastic bag and place it into the box.
Do not place the new drum cartridge in an upright position.
If you have a used drum cartridge no longer needed, contact your local Fuji Xerox representative for its
disposal.
6
Remove the protection cover from the drum cartridge.
7
Slide the new drum cartridge into the printer until it stops.
To Next Page
