3 Maintenance
88
Maintenance
3
1 Make sure that the machine is not operating,
and open the front cover.
2 Rotate the release lever of the drum cartridge
cover counterclockwise.
3 Lower the cover.
Note • You can now see the drum cartridge.
4 Slowly slide out the cleaning bars housed
within the LED printhead until it stops. The
cleaning bars are located in the cleaning
connection just under the drum cartridges (R1,
R2, R3, or R4).
Note • Slide out the cleaning bars until you see
"zzz".
Important • Do not remove the cleaning bars from the
housing.
5 Slowly slide the cleaning bars back into place.
Note • Clean the four LED printheads (R1 to R4) by
sliding the cleaning bars back and fourth for
two or three times, respectively.
