3 Maintenance
82
Maintenance
3
6 Carefully place the old waste toner container into
the empty box with both hands.
7 Rotate the release lever of the drum cartridge
cover counterclockwise.
8 Lower the cover.
Note • You can now see the drum cartridge.
9 Slowly slide out the cleaning bar housed within
the LED printhead until it stops. The cleaning bars
are located in the cleaning connection just under
the drum cartridges R1, R2, R3, and R4.
Important • Do not remove the cleaning bar from the
housing.
Note • Slide out the cleaning bar until you see "".
10 Slowly slide the cleaning bar back into place.
Note • Clean the four LED printheads R1 to R4 by
sliding the cleaning bar back and forth for two
or three times respectively.
Never throw a waste toner bottle into
an open flame. Toner may catch fire and
cause burn injuries or explosion.
If you have a used waste toner bottle no
longer needed, contact your local Fuji
Xerox representative for its disposal.
To Next Page
