Fuji Xerox DocuPrint CM305 df Service Manual

2 - 175
Chapter 2 Troubleshooting
FIP-1.N3 Noise: During Printing (Checking for other items than "power on noise")
Step Check
Remedy
Yes No
Possible causative parts:
HOLDER ASSY SEPARATOR (PL2.1.5)
ROLL ASSY FEED (PL3.2.4)
ROLL ASSY REGI (PL3.2.9)
ROLL REGI METAL (PL3.2.10)
PHD ASSY (PL4.1.21)
FUSING UNIT (PL6.1.1)
TRANSFER ASSY (PL6.1.7)
DRIVE ASSY SUB (PL7.1.1)
DRIVE ASSY MAIN (PL7.1.2)
FAN (PL8.2.8)
FEEDER ASSY DUP AIO STD(PL11.1.1)
ADF ASSY (PL10.1.3)
ROLL ASSY FEED (PL10.1.5)
PAD ASSY SEPARATOR (PL10.1.6)
1
Checking the ADF feeding.
Does the noise arise from the printer when the original is fed
from the ADF?
Go to step 2. Go to step 4.
2
Checking the original.
Does the original meet the ADF spec?
Go to step 3
END, change the
original.
3
Checking the KIT ADF FEED ROLL & SEPARATOR ROLL
Are there any damages or foreign substances on the
Roller?
Remove the
foreign
substances or
Replace the KIT
ADF FEED ROLL
& SEPARATOR
ROLL. (Refer to
REP9.2.)
Replace the KIT
ADF ASSY. (Refer
to REP9.1.)
4
Checking the paper feeding.
Does the noise arise from the printer when the paper is fed
from the Tray 1?
Go to step 5. Go to step 9.
5
Checking the paper condition in the Paper Cassette.
Is the paper dry and recommended paper?
Go to step 7.
Replace the paper
with a new dry and
recommended
one, then go to
step 6.
6
Checking noise when the paper is fed from the Tray 1.
Does the noise arise from the printer?
Go to step 7. End of work.
7
Checking the HOLDER ASSY SEPARATOR in the Paper
Cassette for rotation.
Remove the Paper Cassette from the printer.
Does the SEPARATOR ROLLER rotate smoothly?
Turning it with your finger.
Go to step 8.
Replace the KIT
HOLDER ASSY
SEPARATOR.
(Refer to REP2.2.)
8
Checking the ROLL ASSY FEED for rotation.
Remove the Paper Cassette from the printer.
Checked by [Digital Output] - [Main Motor] in [IOT Diag] and
then enter the [Digital Output] - [Tray1 Feed Solenoid] in
[IOT Diag] of diagnosis.
Does the noise arise from this Roller?
Replace the KIT
ROLL ASSY
FEED. (Refer to
REP3.3.)
Go to step 12.
