Chapter 5 Parts List
PL 2.1 Paper Cassete [List]
ITEM PARTS No. DESCRIPTION A.C
1 050K 64150 CASSETTE ASSY 250 MG AIO (with 19,21) 5010
2 015K 75520 PLATE ASSY BOTTOM 50B1
3 - - SPRING N/F L 50B2
4 - - SPRING N/F R 50B3
5 - - HOLDER ASSY SEPARATOR 50B4
6 038E 36920 GUIDE SIDE L 50B5
7 007E 75020 GEAR PINION 50B6
8 038K 18430 GUIDE SIDE ASSY R 50B7
9- -- -
10 - - - -
11 - - - -
12 - - - -
13 - - - -
14 003E 73390 LATCH BOTTOM L 50B8
15 003E 73930 LATCH BOTTOM R 50B9
16 809E 82580 SPRING LATCH B 50BB
17 050K 61170 TRAY ASSY EXTENSION 50BC
18 848K 52262 HOUSING CASSETTE 250 50BD
19 003K 87520 HANDLE ASSY CST MG AIO 50BE
20 - - - -
21 050K 63890 TRAY ASSY CST 250 AIO (with 2-8,14-18,25-27) 5012
22 032E 26410 GUIDE BOTTOM L 50BF
23 032E 26420 GUIDE BOTTOM R 50BG
24 019K 09240 PAD ASSY BOTTOM 50BH
25 038K 18440 GUIDE ASSY END 50BJ
26 003E 76750 LATCH HSG END 50BK
27 809E 72211 SPRING LATCH 50BL
28 - - TRAY ASSY EXT OWN (with 17,25-27) 50BM
99 675K 62840 KIT GUIDE SIDE (with 6-8) 50BN
