2 - 39
Chapter 2 Troubleshooting
FIP-1.3 005-301: ADF Cover Open
Step Check
Remedy
Yes No
Possible causative parts:
PWBA ESS AIO (PL8.1.2)
KIT ADF ASSY (PL10.1.3)
COVER TOP ADF (PL10.1.4)
1
Checking the ADF Cover.
Is the ADF Cover completely closed?
Go to step 2.
Close the ADF
Cover.
2
Checking the COVER TOP ADF
Are there any damages on the COVER TOP ADF?
Replace the
COVER TOP ADF.
Go to step 3.
3
Checking the connector connection
Reseat the connector (P/J1003) on the PWBA ESS AIO.
Does the error still occur when copying?
Go to step 4. End of work.
4
Checking after replacing the ADF ASSY
Replace the KIT ADF ASSY. (Refer to REP9.1.)
Does the error still occur when copying?
Replace the KIT
PWBA ESS AIO.
(Refer to REP8.2.)
End of work.
To Next Page
