Fujitsu AB G36LRTE Series Service Manual

INDOOR UNIT
CASSETTE
AUYG22LVLA
812016.01.27
DECORATION PANEL
UTG-UFYD-W
Name and Shape Q’tyName and Shape Q’ty Name and Shape Q’ty
Connector cover
1
For covering connector
Tapping Screw
(M5 × 12 mm)
4
Mounting decoration panel
Tapping Screw
(M4 × 12 mm)
1
Mounting connector cover
L angle
2
Mounting the Hook
Wire to the decoration panel
Hook wire
2
Suspending the decoration panel
Screw [pitch small]
(M4 × 10 mm)
2
Mounting the Hook wire (for metals)
Screw [pitch large]
(M4 × 10 mm)
4
Mounting the L angle
and Hook wire (for resins)
Special nut A
(Large flange)
4
For installing indoor unit
Special nut B
(Small flange)
4
For installing indoor unit
Template
(Carton top)
1
For cealing openings cutting
Also used as packing
Drain hose
1
For installing drain pipe
Hose Band
1
For installing drain hose
Drain hose
insulation
1
For installing drain pipe
Remote control
1
Battery
2
Remote control
holder
1
Tapping screw
(M3 × 12mm)
2
Mounting the remote control holder
Cable tie
2
For electrical wiring
Wire clamper
1
For electrical wiring
Coupler heat insulation
(Small)
1
For indoor side pipe joint (liquid pipe)
Coupler heat insulation
(Large)
1
For indoor side pipe joint (gas pipe)
