INDOOR UNIT (C ontinued)
422 Clamp NK-10N 9359183006 9359183006 9359183006 9359183006 9359183006 9359183006
439 Drain Pan Wire 9358598009 9358598009 9358598009 9358598009 9358598009 9358598009
443 Arm Bracket 9359281009 9359281009 9359281009 9359281009 9359281009 9359281009
470 Separate Wall-B 9358585009 9358585009 9358585009 9358585009 9358585009 9358585009
472 Grille Support 9358602003 9358602003 9358602003 9358602003 9358602003 9358602003
473 Filter Bracket 9358607008 9358607008 9358607008 9358607008 9358607008 9358607008
488 Grill-F 9358532010 9358532010 9358532010 9358532010 9358532010 9358532010
500 Protect Cover 9358564004 9358564004 9358564004 9358564004 9358564004 9358564004
502 Support Stay 9358599006 9358599006 9358599006 9358599006 9358599006 9358599006
503 Louver Shaft 9358557006 9358557006 9358557006 9358557006 9358557006 9358557006
505 Louver Stopper 9358555002 9358555002 9358555002 9358555002 9358555002 9358555002
506 Louver Rod 9358559000 9358559000 9358559000 9358559000 9358559000 9358559000
508 Cosmetic Panel-R 9358535011 9358535011 9358535011 9358535011 9358535011 9358535011
509 Cosmetic Panel-L 9358536018 9358536018 9358536018 9358536018 9358536018 9358536018
514 Control Box Cover 9359097006 9359097006 9359097006 9359097006 9359097006 9359097006
520 Flap Base 9358537015 9358537015 9358537015 9358537015 9358537015 9358537015
521 Louver Link Cover 9358558003 9358558003 9358558003 9358558003 9358558003 9358558003
552 Insulation (Eva.)-R 9358575000 9358575000 9358575000 9358575000 9358575000 9358575000
553 Insulation (Eva.)-L 9358857007 9358857007 9358857007 9358857007 9358857007 9358857007
554 Flap Link-Upper (Step Motor-V) 9358551004 9358551004 9358551004 9358551004 9358551004 9358551004
555 Flap Link-Lower (Step Motor-V) 9358552001 9358552001 9358552001 9358552001 9358552001 9358552001
558 Motor Rod-A (Step Motor-V) 9358550007 9358550007 9358550007 9358550007 9358550007 9358550007
574-1 Evaporator Fixture-R (Bracket) 9358589007 9358589007 9358589007 9358589007 9358589007 9358589007
574-2 Evaporator Fixture-L (Bracket) 9358590003 9358590003 9358590003 9358590003 9358590003 9358590003
577 Catch TL-119 9359096009 9359096009 9359096009 9359096009 9359096009 9359096009
578 Base Bracket (Reinforcement Metal) 9358586006 9358586006 9358586006 9358586006 9358586006 9358586006
580 Top Cover 9358534014 9358534014 9358534014 9358534014 9358534014 9358534014
581 Protector, Metal (Fan Motor) 9359282006 9359282006 9359282006 9359282006 9359282006 9359282006
588-1 Evaporator Bracket-R 9358587003 9358587003 9358587003 9358587003 9358587003 9358587003
588-2 Evaporator Bracket-L 9358588000 9358588000 9358588000 9358588000 9358588000 9358588000
625 Cord Bushing KR-51 9359240006 9359240006 9359240006 9359240006 9359240006 9359240006
628 Locking Spacer-B 313005446558 313005446558 313005446558 313005446558 313005446558 313005446558
629-1 EMI Filter 0400247074 0400247074 0400247074 0400247074 0400247074 0400247074
652-1 Thermistor Holder Pipe 313806262805 313806262805 313806262805 313806262805 313806262805 313806262805
653-1 Bolt (Fan Motor Fixing) 0700156014
0700190018
0700156014 0700156014 0700156014 0700156014 0700156014
653-2 Bolt 0700190018 0700190018 0700190018 0700190018 0700190018
684 Motor Base 9358562000 9358562000 9358562000 9358562000 9358562000 9358562000
689 Screw, Grip Tapping 9357837000 9357837000 9357837000
SN+4016 ZNY w/Grip
731-2 Holder (Guide Rail) 0600241018 0600241018 0600241018 0600241018 0600241018 0600241018
-- -- --- -- -- -- --- --
743 Remote Control Unit Holder 9305642014 9305642014 9305642014 9305642014 9305642014 9305642014
755 Casing Cover 9358544006 9358544006 9358544006 9358544006 9358544006 9358544006
764 Drain Cap 9358746004 9358746004 9358746004 9358746004 9358746004 9358746004
771 Panel Assy 9359076018
9900203016
9359076018 9359076018 9359076018 9359076018 9359076018
735
790
800
810
Distributor As 9373034018 9373034018 9373034018 9373034032 9373034025 9373034025
Coupring Pipe Assy not available not available 9373038016 9373038023 9373038023 9373038023
Bypass Pipe Assy 9373032014 9373032014 9373032014 9373032021 9373032021 9373032021
Bypass Pipe B not available not available not available
815-1 Terminal 3P -- -- --- -- -- -- --- -- -- -- --- -- -- -- --- -- -- --- -- --
-- -- --- --
815 Terminal 7P -- -- --- --
-- -- --- -- -- -- --- -- -- --- -- --
9358660102 -- -- --- -- 9358660102 --- -- -- -- 9358660102
824-3 Fuse BET3.15A - 250V 0600222512 0600222512 0600222512 0600222512 0600222512 0600222512
868 PCB Holder 9358547007 9358547007 9358547007 9358547007 9358547007 9358547007
870-1 Arm 9358565001 9358565001 9358565001 9358565001 9358565001 9358565001
870-2 Center Arm 9359280002 9359280002 9359280002 9359280002 9359280002 9359280002
876-1 Step Motor-H 9359106012 9359106012 9359106012 9359106012 9359106012 9359106012
876-2 Step Motor-V 9359105015 9359105015 9359105015 9359105015 9359105015 9359105015
923 Control Box Bracket 9358717004 9358717004 9358717004 9358717004 9358717004 9358717004
982 Cord Clamp 9357864006 9357864006 -- --- -- -- 9357886008 - --- -- -- - 9357886008
R ef.
No.
Des cription
Ord.
Q'ty
P art No.
When you order parts, pleas e make a photocopy of this page
and fill the number of the parts in the "Order" column.
9704561022
(EZ-00101HSE-P)
9704561022
(EZ-00101HSE-P)
9704561022
(EZ-00101HSE-P)
9704561077
(EZ-00210HSE-P)
9704561022
(EZ-00101HSE-P)
9704561077
(EZ-00210HSE-P)
875 Power Supply PCB Assy
2004.03.25 32
AB Y 24UB B JAB Y 14UB B J AB Y 18F B B J AB Y 18UB B J AB Y 24F B B JAB Y 14F B B J
