Fujitsu ABY24LBAJ User Manual

When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
4 Emblem-Rear 9371388014
5 Cabinet-A, Painted 9359797029
6 Cabinet-C, Painted 9363798029
9 Cabinet-B 9363797022
12 Base Assy, Painted 9364145020
13-1 3-Way Valve Assy 9372205075
16 Condenser Assy 9373254010
17 Condenser Sub Assy 9360274182
26-2 Compressor Cover 9372067017
26-3 Compressor Cover-C 9370186000
29 Separate Wall-B 9369625015
32-7 Control Box Metal-G 9369616006
32-8 Control Box Metal-H 9369617003
32-9 Control Box Metal-I 9369618000
32-10 Control Box Metal-J 9369619007
32-11 Control Box-K 9369620010
34 Capacitor (Fan Motor)
Capacitor
9704305015
39 Propeller Fan 9359837015
40 Air seal Plate 9369623004
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOY24LMAL
84 Valve Cover 9363802009
69-3 Bolt, Hex.Socket 301210060360
107 Rubber Seat-A 9358080009
109 Terminal Cover 9370289008
117-3 Hex. Nut w/SP. Washer 301721180114
138 2-Way Valve Assy 9372204061
176 Valve Fixing Plate-A 9363799064
181 ACTPM 9703457012
183-1 Water Seal Plate-B 9369626012
185-2 Rubber Washer 9358078006
203 TR PCB Assy 9704009029
204 Heat Sink-B 9369793004
44 Motor Bracket CTR 9373076018
47 Comp Plate Assy 9363800005
OUTDOOR UNIT
45-1 Motor Bracket-A
9369627002
45-2 Motor Bracket-B
9369628009
45-4 Motor Bracket-D
9369630002
46 Compressor Assy 9373531012
64 Cabinet Left. 9359840022
41 Fan Motor Assy Out 9601754015
3 Fan Guard 9371187013
549 PTC Thermistor 9704265012
629 Coil, Choke 9703458019
734 Cabinet Top Plate 9359799023
825-1 EXP Valve Assy 9373251019
875 Filter PCB Assy 9704722010
886 Heat Sink-A 9369792007
964 Seperate Wall Ins B 9360074201
764 Drain Cap 313166024302
788 Thermistor (Disc Temp. ) 9704219077
815 Terminal-6P 9358660089
824 Fuse 0600086039
824-3 Fuse 0600222512
824-4 Fuse 0600222529
823 Fuse Holder 0500158072
965 Frange nut 9358079003
887-1
----
Reactor Cover 9369622007
910 Strainer-B 9365099018
949-1 Screw , Painted 9305648009
960 Accum Support Sheet 9354022010
961 Noise Ins A 9370181005
962 Accum SPT AS 313986353804
963 Acum HLD Rub 9354022010
967 Comp Temp Thermo. 9900156015
9704729019
373 Grip 9352157004
381-2 Locking Spacer 0600035020
381-3 Locking Spacer 0600118051
408 Special Nut M8 9355091008
411 Holder 9372066010
412 Terminal Packing 9370290004
477 Bell-Mouth 9359809012
527 Protection Net 9359844013
353 Thermistor Assy-Out 9703516054
235 Thermo.(Heat Exchi) 9704220059
236 Controller PCB Assy 9704719072
(EZ-003PHUE-C)
255 Insulation ( Heat Sink ) 9370844009
333 Accumulator 9351997014
343 Solenoid 9900165024
343-1 Coil (EXP Valve) 9970006012
344 4-way Valve 9900163013
292004.09.15
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOY24LMAL
