INDOOR UNIT
Control unit
2009.07.13 29
102
104
105
101
103
106
101 Control Box 9358600016
-- Room Thermistor Assy 9703299087
103 Controller PCB Assy (18)
103 Controller PCB Assy (24) 9707393354
9707393347
102 Control Box Cover Assy 9359097006
105 Terminal 3P 9306489045
106 Terminal 3P 9703345012
9707398014
9358600054
9703299087
9707393545
9707393569
9359097006
9306489045
9703345012
9707398113104 Power Supply PCB Assy
Ref. Description
Part number
LAT LBT
