2012.08.29 50
81
82
83
84
ABYF24LBT
ABYF22LBT
82
83
84
81
81 Evaporator Total Assy 9359051275 9359051268
82 Bypass Pipe Assy 9377819017 9377821010
83
84
Distributor Assy 9371325354 9371325361
Coupling Pipe Assy 93730383999373038382
ABYF22LBT
ABYF24LBT
Ref. Description
Part number
ABYF18LBT
INDOOR UNIT
ABYF18LBT
Evaporator
CEILING TYPE
