92017.07.07
INDOOR UNIT
CASSETTE
AUYG22LVLA
DECORATION PANEL
UTG-UFYD-W
700 mm
30 mm
49 mm
700 mm
570 mm
245 mm
530 mm
(
Hanging bolt position
)
540 mm
(
Hanging bolt position
)
