Accessories
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Screw A
10 mm
16
Operating manual 1 Screw B
10 mm
6
Grille 1 Cable clip 2
Bracket frame 1 Cable tie 3
Bushing 1
- 211 -
10-3. Auto louver grille kit (UTD-GXTB-W) 10. Optional parts installation
SYSTEM
DESIGN
SYSTEM
DESIGN
