Heating capacity (Twin)

Compact cassette type
Model: AUXG24KVLA × 2
AFR
m
3
/h
1,860
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 12.26 4.49 11.97 4.51 11.67 4.53 11.40 4.58 10.72 4.71
-10 -11 13.62 4.68 13.29 4.70 12.97 4.72 12.66 4.78 11.91 4.91
-5 -7 14.97 4.87 14.61 4.89 14.26 4.92 13.93 4.97 13.10 5.11
0 -2 15.77 5.06 15.39 5.08 15.02 5.11 14.67 5.17 13.79 5.31
5 3 16.88 4.61 16.48 4.63 16.08 4.66 15.70 4.71 14.77 4.84
7 6 17.33 4.60 16.91 4.63 16.50 4.65 16.12 4.70 15.16 4.83
10 8 18.05 4.59 17.61 4.62 17.18 4.64 16.78 4.69 15.79 4.82
15 10 19.24 4.58 18.78 4.60 18.32 4.62 17.90 4.68 16.83 4.81
20 15 20.44 4.56 19.95 4.58 19.46 4.61 19.01 4.66 17.88 4.79
24 18 21.40 4.55 20.88 4.57 20.37 4.59 19.90 4.64 18.72 4.78

Duct type
Model: ARXG24KMLA × 2
AFR
m
3
/h
2,200
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 12.26 4.49 11.97 4.51 11.67 4.53 11.40 4.58 10.72 4.71
-10 -11 13.62 4.68 13.29 4.70 12.97 4.72 12.66 4.78 11.91 4.91
-5 -7 14.97 4.87 14.61 4.89 14.26 4.92 13.93 4.97 13.10 5.11
0 -2 15.77 5.06 15.39 5.08 15.02 5.11 14.67 5.17 13.79 5.31
5 3 16.88 4.61 16.48 4.63 16.08 4.66 15.70 4.71 14.77 4.84
7 6 17.33 4.60 16.91 4.63 16.50 4.65 16.12 4.70 15.16 4.83
10 8 18.05 4.59 17.61 4.62 17.18 4.64 16.78 4.69 15.79 4.82
15 10 19.24 4.58 18.78 4.60 18.32 4.62 17.90 4.68 16.83 4.81
20 15 20.44 4.56 19.95 4.58 19.46 4.61 19.01 4.66 17.88 4.79
24 18 21.40 4.55 20.88 4.57 20.37 4.59 19.90 4.64 18.72 4.78
- 71 -
6-3. Model: AOYG54KRTA 6. Capacity table
OUTDOOR UNIT AOYG36-54KRTA OUTDOOR UNIT AOYG36-54KRTA
