- (04 - 60) -
OUTDOOR UNIT AO

G30L4
OUTDOOR UNIT AO

G30L4
Indoor unit : 7000Btu + 12000Btu + 12000Btu + 14000Btu
z
Indoor unit : 7000Btu + 12000Btu + 12000Btu + 18000Btu
z
Indoor unit : 7000Btu + 12000Btu + 14000Btu + 14000Btu
z
Indoor unit : 9000Btu + 9000Btu + 9000Btu + 9000Btu
z
TC : Total Capacity (kW)
IP : Input Power (kW)
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+12+12+14
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 7.86 3.13 7.68 3.19 7.49 3.26 7.30 3.32 7.11 3.39
-5 -7 8.85 3.26 8.63 3.33 8.42 3.40 8.21 3.47 8.00 3.54
0 -2 10.20 3.44 9.95 3.51 9.71 3.58 9.47 3.58 9.23 3.58
5 3 11.49 3.44 11.21 3.51 10.94 3.58 10.67 3.58 10.39 3.58
7 6 12.29 3.44 11.99 3.51 11.70 3.58 11.41 3.58 11.12 3.58
10 8 12.78 3.44 12.47 3.51 12.17 3.58 11.86 3.58 11.56 3.58
15 10 12.71 3.20 12.41 3.26 12.11 3.33 11.81 3.34 11.50 3.34
20 15 10.81 2.21 10.55 2.30 10.30 2.30 10.04 2.30 9.78 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+12+12+18
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 8.06 3.11 7.87 3.17 7.68 3.24 7.49 3.30 7.30 3.37
-5 -7 9.07 3.25 8.86 3.31 8.64 3.38 8.42 3.45 8.21 3.52
0 -2 10.46 3.42 10.21 3.49 9.96 3.56 9.71 3.58 9.46 3.58
5 3 11.78 3.44 11.50 3.51 11.22 3.58 10.94 3.58 10.66 3.58
7 6 12.60 3.44 12.30 3.51 12.00 3.58 11.70 3.58 11.40 3.58
10 8 13.10 3.44 12.79 3.51 12.48 3.58 12.17 3.58 11.86 3.58
15 10 13.04 3.18 12.73 3.24 12.42 3.31 12.11 3.34 11.80 3.34
20 15 11.09 2.21 10.82 2.30 10.56 2.30 10.30 2.30 10.03 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
7+12+14+14
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 8.00 3 .13 7.81 3.19 7.62 3.26 7.43 3.32 7.24 3.39
-5 -7 9.00 3.26 8.78 3.33 8.57 3.40 8.35 3.47 8.14 3.54
0 -2 10.37 3.44 10.12 3.51 9.88 3.58 9.63 3.58 9.38 3.58
5 3 11.68 3.44 11.40 3.51 11.13 3.58 10.85 3.58 10.57 3.58
7 6 12.50 3.44 12.20 3.51 11.90 3.58 11.60 3.58 11.31 3.58
10 8 12.99 3.44 12.69 3.51 12.38 3.58 12.07 3.58 11.76 3.58
15 10 12.93 3.20 12.62 3.26 12.32 3.33 12.01 3.34 11.70 3.34
20 15 11.00 2.21 10.73 2.30 10.47 2.30 10.21 2.30 9.95 2.30
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
9+9+9+9
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-10 -11 7.95 3.26 7.76 3.33 7.57 3.40 7.38 3.47 7.19 3.54
-5 -7 8.78 3.37 8.57 3.44 8.36 3.51 8.15 3.58 7.94 3.58
0 -2 9.97 3.44 9.73 3.51 9.49 3.58 9.25 3.58 9.02 3.58
5 3 11.03 3.44 10.77 3.51 10.51 3.58 10.25 3.58 9.98 3.58
7 6 11.87 3.44 11.58 3.51 11.30 3.58 11.02 3.58 10.74 3.58
10 8 12.34 3.44 12.05 3.51 11.75 3.58 11.46 3.58 11.16 3.58
15 10 12.28 3.20 11.99 3.26 11.70 3.33 11.40 3.34 11.11 3.34
20 15 10.44 2.21 10.19 2.30 9.94 2.30 9.70 2.30 9.45 2.30
