Models
:
ABY18FBBJ / AOY18FNBK
Cooling
: Flare coupling
Refrigerant pipe
15.88 mm (5/8")
Refrigerant pipe
9.52 mm (3/8")
Charging valv
e
INDOOR UNIT
Evapor
ator
Capillar
y tube
Compressor
Strainer
OUTDOOR UNIT
Condenser
Models
:
ABY24FBBJ / AOY24FNBK
Strainer
Refrigerant pipe
15.88 mm (5/8")
Refrigerant pipe
9.52 mm (3/8")
Capillar
y tube
Charging valv
e
Compressor
OUTDOOR UNIT
INDOOR UNIT
Evapor
ator
Condenser
2004.02.16
6
6
8
Table of Contents
Table of Contents
1
Specifications
2
Electrical Data
3
Fan Motor
3
Outline and Dimensions
4
Refrigerant System Diagram
6
Circuit Diagram
9
Error Display
13
Pcb Circuit Diagram
14
DISASSEMBLY ILLUSTRATION (Indoor Unit)
16
DISASSEMBLY ILLUSTRATION (Outdoor Unit)
23
PARTS LIST (Indoor Unit)
32
PARTS LIST (Outdoor Unit)
34
Standard Accessories
36
Indoor Unit Accessories
36
