Fujitsu AOY14LFBC Service Manual

2005.04.22
15
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
1 Top Panel 9308883025
2 Top Panel Seal 9309228016
3 Cabinet 9308878021
4 Blow Down Grille 9308884015
5 Cabinet-R 9308879028
6 Fan Ring 9308885012
7 Grip 9308880017
8 Switch Cover 9308882028
9 Protective Net 9312026012
10 4-Way Valve Assy 9313755027
11 Expansion Valve Assy 9311641018
12 Dryer 9312056002
13 Condenser 9311381037
14 Thermistor Spring-A 313728262708
15 Thermistor Spring-A 9300089012
16 Propeller Fan 9309909014
17 Nut 9304902003
18 Motor Bracket 9308872012
19 Separator 9312032013
20 Base Assy, Painted 9308869081
21 3-Way Valve Assy 9313554019
22 2-Way Valve Assy 9313064013
24 Cord Clamp 9307271014
25 Terminal 9306489038
26 Inverter PCB Assy 9705622029
27 TR PCB Assy 9705628014
28 ACTPM 9703457012
29 Fuse 0600036027
31 Transformer 9705071018
32 Expansion Valve Coil 9900057039
33 Choke Coil 9703458019
34 Fan Motor 9601815013
35 Compressor Assy 9313764012
36 Emblem 9312633012
37 Heat Exchanger Thermistor 9704220028
38 Discharge Temperature Thermistor
Outdoor Temp. Thermistor
9704219091
39 Solenoid Coil 9970033018
---
--- IPM 9705441026
9308883025
9309228016
9308878021
9308884015
9308879028
9308885012
9308880017
9308882028
9312026012
9313755027
9311641018
9312056002
9311381037
313728262708
9300089012
9309909014
9304902003
9308872012
9312032013
9308869081
9313554019
9313064013
9307271014
9306489038
9705622012
9705628014
9703457012
0600036027
9705071018
9900057039
9703458019
9601815013
9313764012
9312633012
9704220028
9704219091
9970033018
9705441026
---
ACTPM 97034570129703457012
97035160479703516047
Ref.
No.
Description
Part No.
AOY14LFBC AOY18LFBC
Ord.
Q'ty
