500 Protect Cover 9358564004 9358564004
502 Support Stay 9358599006
9358599006
503 Louver Shaft 9358557006
9358557006
505 Louver Stopper 9358555002
9358555002
506 Louver Rod 9358559000
9358559000
508 Cosmetic Panel-R 9358535011
9358535011
509 Cosmetic Panel-L 9358536018
9358536018
514 Control Box Cover 9359097006
9359097006
520 Flap Base 9358537015
9358537015
521 Louver Link Cover 9358558003 9358558003
552 Insulation (Eva.)-R 9358575000 9358575000
553 Insulation (Eva.)-L 9358857007
9358857007
554 Flap Link-Upper (Step Motor-V) 9358551004
9358551004
555 Flap Link-Lower (Step Motor-V) 9358552001
9358552001
558 Motor Rod-A (Step Motor-V) 9358550007
9358550007
574-1 Evaporator Fixture-R (Bracket) 9358589007
9358589007
574-2 Evaporator Fixture-L (Bracket) 9358590003
9358590003
577 Catch TL-119 9359096009
9359096009
578 Base Bracket (Reinforcement Metal) 9358586006
9358586006
580 Top Cover 9358534014 9358534014
581 Protector, Metal (Fan Motor) 9359282006 9359282006
588-1 Evaporator Bracket-R 9358587003 9358587003
588-2 Evaporator Bracket-L 9358588000 9358588000
625 Cord Bushing KR-51 9359240006 9359240006
628 Locking Spacer-B 313005446558 313005446558
629-1 EMI Filter 0400247074 0400247074
652-1 Thermistor Holder Pipe 313806262805 313806262805
653-1 Bolt (Fan Motor Fixing) 0700156014 0700156014
653-2 Bolt 0700190018 0700190018
684 Motor Base 9358562000 9358562000
731-2 Holder (Guide Rail) 0600241018 0600241018
743 Remote Control Unit Holder 9305642014 9305642014
755 Casing Cover 9358544006 9358544006
764 Drain Cap 9358746004 9358746004
771 Panel Assy 9359076117 9359076117
735
790
800
Distributor As 9373034032 9373034025
Coupring Pipe Assy 9373038023
Bypass Pipe Assy 9373032021 9373032021
815-1 Terminal 3P
9373038153
9900203016 9900203016
824-3 Fuse BET3.15A - 250V 0600222512 0600222512
868 PCB Holder 9358547007 9358547007
870-1 Arm
9358565001 9358565001
870-2 Center Arm 9359280002 9359280002
876-1 Step Motor-H 9359106012 9359106012
876-2 Step Motor-V 9359105015 9359105015
923 Control Box Bracket 9358717004 9358717004
982 Cord Clamp 9357886008 9357886008
9704561077
(EZ-00210HSE-P) (K01AL-0408HSE-PO)
9704561190875 Power Supply PCB Assy
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT (Continued)
ABY24LBAJ
Ref.
No.
Description
Ord.
Q'ty
Part No.
ABY18LBAJ
272004.09.08
