REFRIGERANT SYSTEM DIAGRAM
CAPILLARY
TUBE
COMPRESSOR
ACCUMULATOR
HEAT COOL
STRAINER
2-WAY
VALVE
EXPANSION
VALVE
3-WAY
VALVE
4-WAY VALVE
OUTDOOR UNIT
INDOOR UNIT
Models : ABY18LBAJ / AOY18LMAKL
ABY24LBAJ / AOY24LMAL
HEAT EXCHANGER
HEAT EXCHANGER
42004.08.06
