When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
Ref. Description
Part number
AOY30UNBWL
Ref. Description
Part number
AOY30FNBWL
1
9374417018
Top Panel Sub Assy
2 9374094066Front Panel
3
9374330010
Fan Guard
4
9374173013
Grip Side
5
9374415038
Service Panel Sub Assy
6
9351355005
Emblem-Rear
7
9374416035
Right Panel Sub Assy
8
9374418039
Motor Bracket Sub Assy
9
9366378013
Propeller Fan Assy
10
9601671060
Fan Motor
11
9374433056
Condenser Assy
12
9374413034
Separate Wall Sub Assy
13
9355350006
Accumulator Support-B
14
9374166046
Base Assy
15
9372205044
3-Way Valve Assy
16
9372205075
3-Way Valve Assy
17
9372558089
Compressor Assy
18
9374338016
Accumulator
19 9372369012Muffler
20
9900163013
4-Way Valve
32
9900165055
Solenoid
21 9374274024Check Valve Assy
22 9372524015Strainer Assy
23
9369128004
Distributor
24
9372197325
Capillary Assy
25
9704299024
Controller PCB Assy
26 9900269081Running Capacitor
27
9351770013
Capacitor Clamp
28
9900074029
Main Relay
29
9900203023
Terminal 5P
30
9900039011
Transformer
31
9900270049
Capacitor (Fan)
34
9374255030
Protective Net
35
36
46
37
41
45
43
42
40
39
38
44
9374174010
Valve Cover
9371512013
Cover Gasket (Comp)
9371511016
Terminal Cover (Compressor)
9351049010
Rubber Seat (Compressor)
9374430031
Compressor Cover
9357804002
Thermostat Holder
0000361224
Varistor
0600280154
Varistor (Arrester)
313394274808
Capillary Holder Rubber
313728262708
Thermo. Spring A
9900200015
Relay on PCB
9900037048
Thermistor (Out Temp)
9900043049
Heat Exchanger Thermistor
9361140257
Belt Heater
313728251908
4-Way Valve Rubber
9300301015
Special Nut M5 (compressor)
9372246054
Discharge B Assy
9374469017
Inlet Pipe (Condenser) C Assy
9374266050
Outlet Pipe (Condenser) A Assy
9373461067
Inlet Pipe (Condenser) A Assy
9900038038
Thermistor-Discharge
1 9374417018Top Panel Sub Assy
2 9374094066Front Panel
3
9374330010Fan Guard
4 9374173013Grip Side
5 9374415038Service Panel Sub Assy
6 9351355005Emblem-Rear
7 9374416035Right Panel Sub Assy
8 9374418039Motor Bracket Sub Assy
9 9366378013Propeller Fan Assy
10 9601671060Fan Motor
11
9374433063Condenser Assy
12 9374413034Separate Wall Sub Assy
13 9355350006Accumulator Support-B
14
9374166046Base Assy
15 93722050443-Way Valve Assy
16 93722050753-Way Valve Assy
17 9372558089Compressor Assy
18 9374338016Accumulator
21 9374274024Check Valve Assy
22 9372524015Strainer Assy
23 9369128004Distributor
24 9372197349Capillary Assy
26 9900269081Capacitor Plastic
27 9351770013Capacitor Clamp
28 9900074012Relay
29
35
9900203023Terminal 5P
31
33
34
9900270049Capacitor (Fan)
9371512013Cover Gasket (Comp)
9371511016Terminal Cover (Compressor)
9351049010Rubber Seat (Compressor)
9374430031Compressor Cover
9374255030Protective Net
9300301015Special Nut M5 (compressor)
9372264089Discharge A Assy
9374469017Inlet Pipe (Condenser) C Assy
9374174010Valve Cover
39
38
37 313394274808Capillary Holder Rubber
9374266050Outlet Pipe (Condenser) A Assy
9373461067Inlet Pipe (Condenser) A Assy
9900275013Thermostat Outdoor
2007.05.18 21
