Fujitsu AOY54UMAYT User Manual

OUTDOOR UNIT
Ref Description Parts No.
AOY54FMAYT
Ref Description Parts No.
AOY54UMAYT
2012.01.20 22
1 Top Panel Sub Assy 9374417018
2 Front Panel-X, Painted 9374094028
3 Fan Guard 9374330010
4 Side Grip 9374173013
5 Service Panel Sub Assy 9374415014
6 Right Panel Sub Assy 9374416011
7 Motor Bracket Sub Assy 9374418015
8 Propeller Fan Assy 9366378013
9 Motor, Induction 9601671060
10 Condenser-A Assy 9374433025
11 Condenser-B Assy 9374434022
12 Separate Wall-X 9374135011
13 Cap Foot 9374345014
14 Base Assy 9374166022
15 3-Way Valve Assy 9372205044
16 3-Way Valve Assy 9372205099
17 Compressor Assy 9374250011
18 Accumulator Assy 9371615011
20 Pressure Switch 9900276010
23 Check Valve Assy 9374274017
25 Strainer Assy 9372524015
27 Magnetic Relay 9900227012
28 Terminal-7P 9363276039
31 Emblem Rear 9351355005
34 Capacitor (Fan Motor) 9900270049
35 Fuse 0600222529
36 Terminal-2P 9701971015
37 Thermostat (Outdoor) 9900275013
38 Thermostat (Overheat) 9354061002
39 Capillary Assy 9372197332
A Relay 9900287016
---- Belt Heater 9361140240
1 Top Panel Sub Assy 9374417018
2 Front Panel-X 9374094028
3 Fan Guard 9374330010
4 Side Grip 9374173013
5 Service Panel Sub Assy 9374415014
6 Right Panel Sub Assy 9374416011
7 Motor Bracket Sub Assy 9374418015
8 Propeller Fan Assy 9366378013
9 Motor, Induction 9601671060
10 Condenser-A Assy 9374433018
11 Condenser-B Assy 9374434015
12 Separate Wall-X 9374135011
13 Cap Foot 9374345014
14 Base Assy 9374166022
15 3-Way Valve Assy 9372205044
16 3-Way Valve Assy 9372205099
17 Compressor Assy 9374250011
18 Accumulator Assy 9371615011
19 Solenoid 9900165055
20 Pressure Switch 9900186012
21 4-Way Valve 9970035012
22 Compressor Top Temp. Thermistor 9900277017
23 Check Valve Assy 9374274017
24 Coil (Expansion Valve) 9900190026
25 Strainer Assy 9372524015
26 Controller PCB Assy 9705677012
27 Magnetic Relay 9900227012
28 Terminal-7P 9363276039
29 Expansion Valve 9900170028
31 Emblem Rear 9351355005
34 Capacitor (Fan Motor) 9900270049
35 Fuse 0600222529
---- Thermistor Assy 9900274016
----
Drain Cap 313166024302
---- Drain Pipe 9301102000
---- Belt Heater 9361140240
