W7
B
YELLOW
W8
B
BLUE
W12
B
WHITE
W13
B
VIOLET
P
N
+
+
R200
220k
<2W>
POWER_G
OUTDOOR UNIT
AOYG30LETL
CAPACITOR PCB
K05FB-0901HUE-P0
2012.12.06 13
C201
660/
450V
C203
660/
450V
W7
B
YELLOW
W8
B
BLUE
W12
B
WHITE
W13
B
VIOLET
P
N
+
++
C200 - C202
660/
450V
x 3
POWER_G
AOYG36LETL
CAPACITOR PCB
K05FB-0900HUE-P0
